Behncke Cristall2 filter tank for swimming pool, Ø 400

Behncke Cristall² filter tank for swimming pool, Ø 400

These systems, which were created with a high level of technical precision and superior technological know-how, stand out for their simplicity and consequently low installation costs. The systemically significant interactions of all parts, including filter tanks, pumps, valves, etc., produce long-term constants like operational dependability, cost and energy efficiency, low maintenance requirements, and high user-friendliness. Without overlooking the adaptable needs and desires of the customer. Always think one step ahead.

This filter container is constructed from polyethylene and has a glass fiber reinforced polypropylene flanged top with a DN 220 flange. Additionally, comes with a pre-assembled nozzle cross, a drain valve with a hose connection, a manometer, and manual ventilation.

Using the 6-way valve provided, you can quickly and simply select the desired option:

Filtering: operations fundamental posture

Backwash: to clean the filter, water flow is reversed and dumped into wastewater.

Rinse: use fresh water and clean towels to rinse after backwashing

Circulate: when water circulates, it flows past the filter

Empty: to drain the pool water completely

Closed: for the purpose of wintering and upkeep

Product specifications:

• Maximum operating temperature: 30 °C
• Maximum pressure: 1,5 bar
• Diameter: Ø 400
• Valve: 1 ½”
• Equipped with pre-assembled nozzle
• Drain valve with a hose connection
• Without valve set
• With screwed connection
• Dimension: 400 mm x 820 mm

Recommendations:

• Requires a separate purchase of multiport valve
• Not suited for use with a photovoltaic system or when exposed to continuous sun radiation
