The BEHNCKE Splash Control II Measuring and Control System is a single Plug-in, pre-assembled, compact system used for water treatment in private swimming pools. Has two dosing peristaltic pumps.

Usefulness for optimal outcomes. The pumps are mounted directly on the housing to conserve space. The pH level and redox potential are the variables that are being measured.

Product specifications:

• Dosing pumps 2.4 l/h
• Suction lances
• Dosing hose 10 x 4
• In-line probe module with sample water filter and flow control
• 2 x injection valves 1/2" / 10 x 4
• 2 x stopcocks on
• Filter 1/2" / 8 x 5
• 8 x 5 measuring water line PE Splash Control based on the proven DSR controller.
• Reading and parameterization/configuration displays
• Plain text operator guidance in 8 selectable languages
• 2 digital inputs for pause, sample water error or level shutdown
• Two power control outputs for dosing pump control via pulse width modulation (direct switching of the operating voltage)
• Control characteristics: proportional control for both metrics
• A control direction (increase measured value or lower, selectable)
• RC protective circuit to protect the power relay when switching inductive loads, e.g. B. motor-driven dosing pumps
