Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V
Description
Tech Specs
Reviews (1)
Shipping
Easy Returns
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V Photo №1
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V Photo №2
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V Photo №3
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V Photo №4
Code: WH000437

Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V

Code: WH000437
Zodiac
Power, kW
35
Power consumption, kW
5,9
Recommended pool volume, m3
95
Phase
Single
Voltage, V
380 - 400
Heat pump type
inverter

Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V

Looking for a modern, efficient heat pump to keep the water in your pool at the right temperature all year long? The Power Series heat pumps were replaced by the Zodiac PX50 heat pump. Due to its effectiveness, dependability, and simplicity, it provides an excellent price/performance ratio and is a perfect option when buying a heat pump.

Zodiac PX50 has an inverter compressor and a fan motor with boost, smart and eco-silence operating modes, allowing for continuous adjustment of the fan's power input and speed. The pool is effectively heated as a result of intelligent heating. At 28 °C for the air, 28 °C for the water, and 80% relative humidity, it has a COP efficiency rate of 6,7 depending on the size of the pool.

PX50 offers to modify energy usage and noise level in accordance with the precise power requirement.

Product specifications:

  • Heating power: 35 kW
  • Consumed power: 5,9 kW
  • COP: 5,6
  • Recommended water flow: 13 m3h
  • Hydraulic connection: 1 ½ “
  • Power supply: 380-400 V / 3 N~/ 50-60Hz
  • Maximum power (A): 11,8
  • Refrigerant: R32
  • Acoustic power: 75
  • Acoustic pressure at 10 m: 44 db (A)
  • Weight: 128 Kg

Package inclusion: winter cover; condensate drain kit; anti-vibration pads (x5); PVS gaskets, ½ unions, ø 50 connector; remote control kit; free mobile app (with 10 m cable)

Recommendation:

For optimum heat pump performance, the following optional accessories are recommended:

  • iQBrigde RS (code WA000068)
  • Cleaning kit HP (code WMA03491)

Heats the pool with so less power, good addition to the pool
Harsha 26.05.2023
Response
Tell us more about your experience
Write a review
Your name*
E-mail*
Write your product review*
Brand
Zodiac
Type
Pool heat pump and chiller
Power, kW
35
Connection
50 mm
Dimensions, mm
1039 x 410 x 1339
Recommended flow rate m3/h
13
Power consumption, kW
5,9
Recommended pool volume, m3
95
Phase
Single
Voltage, V
380 - 400
Casing material
Plastic
Tube/ spiral material
Titan
Heat pump type
inverter
Type
heat pump
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V
on request
on request
Heats the pool with so less power, good addition to the pool
Harsha 26.05.2023
Response
Tell us more about your experience
Write a review
Your name*
E-mail*
Write your product review*
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V
Zodiac PX50 TD12 35 kW inverter heat pump for pool, 380-400 V
on request
on request
